MODULAR STEEL

Where tradition meets modern refinement. Steel wheels by Tredit are built for the long haul. The superior materials are used to perform at the highest of standards.

Features & Benefits

Where tradition meets modern refinement. Steel wheels by Tredit are built for the long haul. The superior materials are used to perform at the highest of standards.

Today’s steel trailer wheels are constructed from the highest grades of steel alloys. These steels are stronger, lighter, and can carry the loads required by modern towables.

Lifetime structural warranty (for original purchaser) and 1-year finish and paint warranty.

  • High quality steel alloy for strength and weight reduction to other brands
  • All welds inspected for penetration and quality
  • One year coverage on paint, chrome, & galvanized corrosion

Sizes & Specs

DiameterWidthBolt PatternOffsetCapacity
12″4″5 on 4.501,520 lbs
12″4″5 on 4.5″.50″ OS1,520 lbs
13″4.5″5 on 4.5″01,730 lbs
14″5.5″5 on 4.5″02,200 lbs
15″5″5 on 4.5″ 02,200 lbs
15″6″5 on 4.5″02,860 lbs
15″6″6 on 5.5″03,080 lbs
16″6″6 on 5.5″03,860 lbs
16″6″8 on 6.5″ 04,480 lbs
17.5″6.75″8 on 6.5″.50″ OS6,005 lbs

Finishes

5-Lug
6-Lug
8-Lug
