Heavy Duty Trailer Wheels

Features & Benefits

Our heavy-duty trailer wheels are built to take on the high demands that are required for professional grade trailers.

Constructed from the highest grades of steel and aluminum, our heavy-duty wheels are able to take on more carrying capacity, while performing at the highest standards.

Lifetime structural warranty (for original purchaser) and 1-year finish and paint warranty.

  • High quality steel designed for strength and durability
  • All welds are inspected for penetration and quality
MAGNUM- 16″ 8-LUG ALUMINUM DUAL
Wheel TypeDiameterWidthCenter BoreBolt PatternOffsetCapacityFinishes
Aluminum Dual16″6″4.77″8 on 6.5″-5.50″4,000 lbs.Clear Coat- Gloss Black with Milled Window
Aluminum Dual16″6″4.77″8 on 6.5″-5.50″4,000 lbs.Clear Coat- Gloss Silver with Milled Window

*Magnum Center Cap Options (Sold Separately)

Center Cap FinishDescription
Gloss BlackOpen end, bolt-on center cap
Gloss SilverOpen end, bolt-on center cap
ChromeOpen end, bolt-on center cap

16″ 8-Lug Steel Duals (4.77″ & 4.88″ Center Bore)
Wheel TypeDiameterWidthCenter BoreBolt PatternOffsetCapacityFinishes
Dual16″6″4.77″8 on 6.5″-5.503,200 lbsPainted- White, Silver, Black
Dual16″6″4.88″8 on 6.5″-5.503,200 lbsPainted- White, Silver, Black
17.5″ 8-Lug Steel Wheels with + .50 Offset
Wheel TypeDiameterWidthCenter BoreBolt PatternOffsetCapacityStyle OptionsFinishes
Single17.5″6.75″4.77″8 on 6.5″+ .50″6,005 lbsModularPainted- White, Silver, Black
17.5″ 8-Lug Steel Wheels with +.19″ Offset
Wheel TypeDiameterWidthCenter BoreBolt PatternOffsetCapacityStyle OptionsFinishes
Single17.5″6.75″4.77″8 on 6.5″+.19″6,005 lbsConventionalPainted- White, Silver, Black
Single17.5″6.75″4.77″8 on 6.5″+.19″6,005 lbsModularPainted- White, Silver, Black
17.5″ 8-Lug Steel Wheels with +.08″ Offset
Wheel TypeDiameterWidthCenter BoreBolt PatternOffsetCapacityStyle OptionsFinishes
Single17.5″6.75″4.77″8 on 6.5″+ .08″6,005 lbsModularPainted- White, Silver, Black, Galvanized
17.5″ 8-Lug Steel Wheels with – .31″ Offset
Wheel TypeDiameterWidthCenter BoreBolt PatternOffsetCapacityStyle OptionsFinishes
Single17.5″6.75″4.77″8 on 6.5″– .31″6,005 lbsConventional or ModularPainted- Silver
17.5″ 8-Lug Steel Wheels with – .50 Offset
Wheel TypeDiameterWidthCenter BoreBolt PatternOffsetCapacityStyle OptionsFinishes
Single17.5″6.75″4.77″8 on 6.5″– .50″6,005 lbsConventionalPainted- White, Silver, Black
Single17.5″6.75″4.77″8 on 6.5″– .50″6,005 lbsModularPainted- White, Silver, Black
Heavy-Duty 17.5″ 8 on 275mm Steel Duals
Wheel TypeDiameterWidthCenter BoreBolt PatternOffsetCapacityStyle OptionsFinishes
Dual17.5″6.75″8.7″8 on 275mm– 5.50″6,200 lbsConventionalPainted- White, Silver, Black
Heavy-Duty 17.5″ 8-Lug Steel Duals
Wheel TypeDiameterWidthCenter BoreBolt PatternOffsetCapacityStyle OptionsFinishes
Dual17.5″6.75″4.77″8 on 6.5″– 5.59″6,200 lbsConventionalPainted- White, Silver, Black, Galvanized
